Pressure Transmitter PCM390

■ Compact structure

■ Digital circuit compensation

■ Strong anti-interference and excellent long-term stability

■ Small diameter, small size, easy to install and use

■ Available for measurement of absolute pressure, gauge pressure and sealed gauge pressure

■ Multiple electrical connection options

■ SS316L Diaphragm

Applications

■ Hydraulic and pneumatic equipment

■ Servo valve and transmission

■ Air-conditioning system

■ Pipeline system


Product Parameters


Performance parameters


Pressure range

035kPa…25MPa



Pressure reference

Gauge pressure, Absolute pressure, Sealed gauge pressure



Accuracy

±0.5%FS(typ.); ±1%FS(max.)



Hysteresis & repeatability

≤±0.1%FS



Temp. drift

≤±1.5%FS(-20ºC~85ºC)



Response time

<10ms



Service life

≥10×106 pressure cycles



Ambient temp.

-20ºC~80ºC



Medium temp.

-30ºC~105ºC



Storage temp.

-40ºC~120ºC



EMC-interference

IEC 61000-6-3



EMC-immunity

IEC 61000-6-2



Insulation resistance

≥100MΩ/500VDC(200MΩ/250VDC)



Vibration resistance

Sine curve: 20g, 25Hz~2kHz; IEC 60068-2-6



Random: 7.5grms, 5Hz~1kHz; IEC 60068-2-64



Shock resistance

Shock: 100g/11ms;IEC 60068-2-27



Free fall: 1m; IEC 60068-2-32



Protection

IP65



Material

Diaphragm and sensor inside (AISI316L)



Housing and pressure port: (AISI304)



Electrical connection: PA66



Net weight

50g~90g



Size of hexagon

HEX22




Supply & output

Code

B1

B7

B6


Output

4~20mA

0~10V

0.5~4.5V R/M


Supply

12~30VDC

12~30VDC

5VDC




Electrical connection & wiring method



Connector code

J3: Cable outlet

J4: M12




Dimension

In mm





Connection mode

Current  (2 wires)

Red: Supply+

Green: Current output

Pin 1: Supply+

Pin 2: Current output

Pin 3: Pending



Connection mode

Voltage

(3 wires)

Red: Supply+

Green: Ground

Yellow: Voltage output

Pin 1: Supply+

Pin 2: Voltage output

Pin 3: Ground






Connector code

J6: Mini 4 pin

J7: Round Packard



Dimension

In mm





Connection mode

Current  (2 wires)

Pin 1: Supply+

Pin 2: Current output

Pin 3: Pending

Grounding: Pending

Pin 1: Supply+

Pin 2: Current output

Pin 3: Pending



Connection mode

Voltage

(3 wires)

Pin 1: Supply+

Pin 2: Ground

Pin 3: Voltage output

Grounding: Pending

Pin 1: Supply+

Pin 2: Ground

Pin 3: Voltage output






Application of damper

Application


Cavitation, liquid hammer and pressure peak may occur in air or hydraulic systems with varying flow rates, such as the rapid closing of valve or the start and stop of pump. Even at relatively low operating pressures, these problems may occur at the entrance and exit.

PCM390  Pressure Transmitter

Installation

If the fluids containing particles, then nozzle clogging maybe occur, and the vertical installation of the transmitter minimizes the risk of clogging.


Pressure range selection



Pressure range code

Pressure reference

Pressure range

Overpressure

Burst pressure

Remark


35k

G

0~35kPa

300%FS

600%FS

①


70k

G

0~70kPa

300%FS

600%FS

①


100kC

G、A

0~100kPa

200%FS

500%FS



160kC

G

0~160kPa

200%FS

500%FS



250kC

G、A

0~250kPa

200%FS

500%FS



400kC

G

0~400kPa

200%FS

500%FS



600kC

G

0~600kPa

200%FS

500%FS



1MC

G

0~1MPa

200%FS

500%FS



1.6MC

GS

0~1.6MPa

200%FS

500%FS



2.5MC

S

0~2.5MPa

200%FS

500%FS



4MC

S

0~4MPa

200%FS

400%FS



6MC

S

0~6MPa

200%FS

300%FS



10M

S

0~10MPa

200%FS

300%FS

①


16M

S

0~16MPa

150%FS

200%FS

①


25M

S

0~25MPa

150%FS

200%FS

①

Note: (1)G stands for gauge pressure, A, absolute pressure, S, sealed gauge pressure. (2)is non-glass header, please note.
